Piping Module

From scan to as-built pipe — inside AutoCAD. Reconstruct piping straight from point cloud data. Click on the scan and the module measures the real diameter and centerline from the cloud, then builds an accurate 3D solid — exactly as it was built.

These aren't dumb solids: every pipe, fitting and valve carries embedded data — diameter, length, component type and the links between parts — so your model stays intelligent and fully traceable, while remaining a standard AutoCAD solid that opens anywhere: as-built, reverse engineering, SpaceClaim and Navisworks. No proprietary pipe objects to convert.

• Measured from reality — diameter and centerline come from the scan, not a catalog guess.
• A real fitting set — bends, multi-segment bends, reducers, T-joints, flanges, expansion joints and valves (ball, gate, check), each auto-sized to the pipe.
• Associative fittings — edit or move a pipe and connected flanges and valves follow automatically.
• Standardize on demand — sync diameter, bend radius or segment count across a whole chain.
• Full editing — grip-edit, press/pull, join, split and align.
• Traceable & documented — one command generates a piping list (BOM) from the embedded data.

Why 3D Solution: intelligent, data-rich solid pipe modeling in AutoCAD — at a fraction of the cost of the big suites, modular, from €25/month.
